Steel And
Stainless
Steel Bars
Extensive range catering to diverse applications. Choose from premium selections known for their quality, resilience, and unwavering dependability.
Our Products
Wire & Fine Wire
This segment is involved in the production of stainless steel wire rods and wires. Our product's excellence holds strong recognition in the global market.
The wires manufactured within this department primarily serve industries such as shipbuilding, medical, agriculture, springs, vineyards, chemicals, petroleum, automobiles, weaving, braiding, fasteners, food processing, paper mills, welding electrodes, and household applications.
This division possesses the capability to manufacture wire rods across a broad size spectrum ranging from 5.5 mm to 39.5 mm, along with wires ranging from 0.09 mm to 15 mm.
Grades:-
ASTM:201, 202, 204Cu, 302, 303, 304, 304HC, 304L, 309, 310, 310S, 316, 316L, 316Ti, 321, 17-4ph, 15-5ph, 410, 416, 420, 430, 430F etc.
DIN/EN:1.4301, 1.4306, 1.4307, 1.4310, 1.4401, 1.4404, 1.4567, 1.4841, 1.4842, 1.4541, 1.4845, 1.4570, 1.4571, 1.4578,1.4597, 1.4362, 1.4370 and 1.4016
Electrode Grades:ER304, ER304L, ER307, ER307S1, ER308, ER308L, ER308LSi, ER310, ER316, ER316L, Er316LSi, Er347, ER347S1,ER309, ER309L, ER430, ER420
Product Range & Size:-
Medium / Thick wire
0.80 to 16.00 mm
Welding wire
MIG – 0.8 to 1.6 mm, TIG – 1 to 4 mm, Core wire – 2.0 to 5.0
Cold heading wire
2.00 to 16.00 mm
Fine wire
0.09 to 0.70 mm
Electro Polish wire
1.0 to 12.0 mm
Spring wire
0.10 to 12.0 mm
Rope wire
0.10 to 4.0 mm
Redraw wire
0.70 to 5.0 mm
Tie wire (soft range)
0.7 to 4.0 mm
Tie wire (bright drawn)
1.60 to 4.0 mm
Nail wire
1.50 to 16.0 mm
Conveyor belt wire
1.60 to 4.0 mm
Staple Pin wire
0.80 to 1.6 mm
Nickle coated spring wire
0.80 to 1.6 mm
Nicket coated base wire for spring
2 to 4 mm
Testing Facilities:
- Computerised tensile testing machine (capacity range 20kg to 40 ton)
- Bend testing, wrap testing, torsion testing machine
- Hardness testing machine
- Microscope with image analyser with micro photo facilities
- IGC test facilities
- Cold upset test facility
- PMI tester(Niton gun X-ray analyser)
- Spectro and Leco analysers for chemical composition-optical emission spectro and gas analysers
- Radioactive contamination testing
Applications
| Supply Condition | Testing Facilities |
|---|---|
| Welding wire | For electrode core wire, submerged arc welding wire,TIG and MIG welding wire |
| Cold heading wire | For nut, bolt, tapping screws, machine screw, Philip head screws, wood screw, screw cross head |
| Weaving / braiding/knitting wire | For meshes, nets, screens, conveyer belts,kitchen appliances, wire cloths |
| Electro polish wire | For pet cages, kitchen ware, grill racks, decorative handles,wire baskets |
| Spring wire | For corrosion resistant springs, heat resistant springs,electronic and electrical appliance |
| Rope wire | For corrosion and wear resistant wire ropes |
| Redraw wire | For further drawing into fine and superfine wires |
| Tie wire | For fastening cables, garden wattles, wattled walls, fencing |
| Staple wire | For corrosion resistant industrial staple |
| Nail wire | For corrosion resistant nails |
